Handheld Portable Sensor Calibrator – Model G06A02 The G06A02 is a compact, portable vibration calibrator designed for quick and reliable verification of accelerometers and vibration sensors. Engineered for accuracy and ease of use, it provides a stable reference source to ensure your measurements remain precise. Key Features: Precise Output – Vibration acceleration amplitude of 1g ±5% at a fixed frequency of 159.2 Hz Low Distortion Signal – Stable sine wave with ≤3% waveform distortion User-Friendly Design – Lightweight, handheld device weighing only 800g Battery Powered – Built-in rechargeable 9V battery with automatic voltage detection Clear Status Indicators – Green for normal voltage, orange for low…
| Vibration Amplitude | 1g±5% |
|---|---|
| Frequency | 159.2 Hz ±1% |
| Output Waveform | Sine wave |
| Waveform Distortion | ±3% |
| Max Load | 70 grams |
| Power | 9V Internal Battery |
| Temperature Range (℃) | 0~40 |
| Size | 52 x 185 mm |
| Weight (grams) | 800 |
| Sensor Mounting | M5 Screw |
